Vent-A-Hood® 42" Black Carbide Under Cabinet Range Hood


Model #:

CLH9-342 BC

Model #: CLH9-342 BC
1475527
Vent-A-Hood
$2,308.00

At a Glance

Product Dimensions 9"h x 42"w x 21"d

The Classic Series features satin trim with a polished logo to enrich any "retro-styled" kitchen setting. Available in standard and custom paint finishes (additional charges may apply). Recommend mounting height is 24" - 27" above the cooking surface.Read More

$2,308.00

Get to know this product.

Product Overview

Product Overview

All Vent-A-Hood products are suitable for use in damp locations (outdoor applications such as a covered patio) when installed in a GFCI protected branch circuit.

LED lights.

Painted finishes only.

Quiet

Turn on a Vent-A-Hood® and you’ll hear only a whisper of air movement, because the Magic Lung® system provides the quietest ventilation available. Vent-A-Hood®s with LED lights also feature SensaSource®. SensaSource® raises the blower speed from low to high based on temperature for optimal grease control, fire safety, and even quieter operation.

How quiet is a Vent-A-Hood®? The test results shown below were generated at a certified independent industry testing lab. All tests were measured at full speed to demonstrate the most accurate sound rating (other manufacturers may use lower speeds for testing which don't reflect accurate operating sound levels).

Vent-A-Hood's® Magic Lung® "multi-blower technology" allows CFM to double, triple, or quadruple with very little effect on sound levels.

Efficient

The powerful Magic Lung® blower traps all cooking contaminants, liquefies grease vapor and removes heat-polluted air. Because the Magic Lung® blower combines sufficient air pressure and constant speed with centrifugal filtration—and because it doesn’t pull air through a filter—it is the most efficient kitchen ventilation available today.

Easy-Cleaning

The Magic Lung® housing snaps apart for easy cleaning in the dishwasher or with warm, soapy water. Moreover, the Magic Lung® is the only ventilation system that collects the grease in the easily cleaned housing rather than in hard-to-reach areas behind a mesh or baffle filter.

Fire-Safe

The Magic Lung® is the only residential ventilation system on the market today that prevents fire from spreading to the rest of the home. Constant speed creates centrifugal pressure that prevents fire from entering the ductwork. As needed, SensaSource® increases blower speed to its normal level to maintain this safety feature.

Powerful

Magic Lung® blowers can be configured to provide the power you need for even the most demanding cooking surface. Each highly efficient Magic Lung® blower supplies 300 CFM of air movement; you can combine multiple blowers in a single Vent-A-Hood® to create the perfect ventilation for your cooking surface.

Useful Documents
Specifications

General Specs

Width (in.)42
Height (in.)9
Duct Size (in.)10
Depth (in.)21
ColorBlack
Manufacturer Warranty5 Year Parts & Labor
Color Finish NameBlack Carbide
Range Hood TypeUnder Cabinet
ADA CompliantNo
ENERGY STAR CertifiedNo
Outdoor ApprovedYes
Appliance Fit Width (in.)42
Maximum CFM900
Bulb TypeLED
Sones Rating6.3
Height Above Cooktop24 - 27
Voltage115
Amp6
Frequency60
Range Hood FeaturesApproved For Outdoors, Heat Sensor, Light
Noise Level (Sones)Standard - (High)
Ventilation TypeDucted
WarningProposition 65 Warning for California Residents
